APPLICATION:
This range of water meter is used to measure the total quantity of cold potable water which consumed in houshold or a resident unit, passing through the pipeline

FEATURES:
LXSY-13S: Liquid sealed register, long clear breading, etc.
Small, light, adopting pointer and word-wheel combination count device, convenient reading.

WORKING CONDITION:
Water temperature：≤40℃ Water pressure：≤1MPa

COMPLIANCE WITH STANDARD:
ISO 4064 (GB/T778-1996)

INDICATION ERROR:
At low zone is±5% from minimum flow rate(qmin)to transitional flow rate(qt)exclusive boundary
At high zone is±2% from transitional flow rate(qt) to overload flow rate(qs)
